Manual

Replacement Parts
C-1
A
PPENDIX
C
Replacement Parts
534 Amp SA3000 Power Module
Table C.1 – 534A SA3000 Power Module
Part Description
1
1. Components are identified in figure 2.2.
Quantity
Rockwell
Part Number
Blower Assembly 1 850011-R
IGBT Phase Module Assembly 3 803430-8S
Capacitor Bank Assembly 1 803430-6S
Pre-charge Assembly 1 850022-3_
115 VAC Power Supply Assembly 1 850100-3_
Disconnect Switch (Optional) (600A, 1000 VAC) 1 65242-8B
Fuse (FPM A, F101A/F102A) (1000A,1000VAC) 2 64676-80P
Local Power Interface Module 1 0-60027
250VA Isolation Transformer (250 VA, 110 VAC) 1 417155-16B
PMI Rack Assembly 1 805401-5R
25KHz Power Supply (2A)
(115 VAC input, 60 VDC output)
1 802268-16R
LEM Sensor (1000A, 5000:1) 3 600595-18A
Ω 3 63481-102TFB
DC Feedback Module 1 0-55350-10
Motor Ammeter (Optional) 1 708208-20R
Motor Voltmeter (Optional) 1 708208-18R
Torque Meter (Optional) 1 708208-17R
Frequency Meter (Optional) 1 708208-19R
Blower Filter 1 69470-3RM
Table C.2 – Capacitor Bank Assembly (803430-6S)
Part Description Quantity
Rockwell
Part Number
Capacitor (7200µF, 500 VDC) 18 600442-30SX
Table C.3 – Blower Assembly (850011-R)
Part Description Quantity
Rockwell
Part Number
Blower (115 VAC) 1 69739-47R
Starter Capacitor (40µF, 240 VAC) 1 69932-24QQ
