Configuration and Diagnostic Software Tool User Manual Owner manual
Table Of Contents
- Content
- 1. Introduction
- 2. Installation
- 3. Optical Interface
- 4. Configuration Tool for GuardShield Safe 2/Safe 4 Light Curtains
- 5. Configuration Tool for MSR42
- 5.1. Introduction
- 5.2. Starting MSR42 Configuration Tool
- 5.3. The menu bar
- 5.4. Main window
- 5.4.1. Tab “Design”
- 5.4.2. Tab “Diagnosis”
- 5.4.3. Tab “Application info”
- 5.4.4. Possible Configurations
- 5.4.5. Micro 400 Light Curtain
- 5.4.6. One Device (2 NC)
- 5.4.7. One or Two Device (OSSDs)
- 5.4.8. Safety override
- 5.4.9. Muting Micro 400
- 5.4.10. Muting other device (OSSDs)
- 5.4.11. Function “EDM” + “Start Release”
- 5.4.12. Function “Stop delay”
- 5.5. Download, Verify & Upload
- 5.6. Muting
- 5.6.1. General
- 5.6.2. Muting lamp
- 5.6.3. Muting sensors
- 5.6.4. Mute dependant override function
- 5.6.5. Sensor output delay function
- 5.6.6. Muting with enable signal
- 5.6.7. Muting disable function
- 5.6.8. Safety light curtain interruption monitoring function
- 5.6.9. 43BMuting time recorder
- 5.6.10. 44BSetup: 2 sensor T-type
- 5.6.11. Setup: four sensor T-type
- 5.6.12. Setup: two sensor L-type
- 5.6.13. Setup: two sensor T-type with enable signal
- 5.7. Blanking
- 6. Appendix
20
Light Curtain Multi-Function Control Module User Manual
Original instructions
• Low Light Intensity (Micro 400)
•Muting (Automatic)
• Safety Override
C Safety Outputs OSSD
Using the Edit button the following parameters may be selected.
•Stop delay
• External Device Monitoring
In the lower portion of the Configuration window is a “System information” field, which gives information about design errors.
By selecting the “Configuration Control” button the corresponding configuration control document will appear in a new window (Figure 26
).
Figure 26: Configuration control document window
5.4.1.2. Basic Configuration
MSR42 (Cat. # 440R-P226AGS-NNR) control units are delivered standard with the “Basic configuration”. The characteristic of this “Basic
configuration” is described in the MSR42 user manual and is shown in the sub-tab “Basic configuration” (Figure 27
).
To set a MSR42 control unit back to the original “Basic configuration” just open the basic configuration sub-tab (Figure 27
), press “Download Default
Configuration” and follow the instructions to download these parameters (See chapter 5.5.1 on page 31)
.
The info output is status information only.
The output may not be used as a safety signal!
