26 MP-Series Integrated Gear Motor Installation Instructions
Publication MP-IN003C-EN-P — April 2003
Axial Load Force Ratings (Zero Radial Load)
Motor Full rpm range
kg (lb)
MPG-A004-031
1
166 (366)
MPG-A004-091
2
166 (366)
MPG-A010-031
3
219 (483)
MPG-A010-091
4
219 (483)
MPG-A025-031
5
423 (933)
MPG-A025-091
6
423 (933)
MPG-A050-031
7
625 (1378)
MPG-A050-091
8
625 (1378)
MPG-A110-031
9
1025 (2259)
MPG-A110-091
10
1025 (2259)
MPG-B010-031
11
219 (483)
MPG-B010-091
12
219 (483)
MPG-B025-031
13
423 (933)
MPG-B025-091
14
423 (933)
MPG-B050-031
15
625 (1378)
MPG-B050-091
16
625 (1378)
MPG-B110-031
17
1025 (2259)
MPG-B110-091
18
1025 (2259)
1
Measurement speeds: 40, 100, 156, 194 rpm.
2
Measurement speeds: 40, 66 rpm.
3
Measurement speeds: 40, 100, 157 rpm.
4
Measurement speeds: 40, 65 rpm.
5
Measurement speeds: 40, 100, 158 rpm.
6
Measurement speeds: 40, 62 rpm.
7
Measurement speeds: 20, 50, 81 rpm.
8
Measurement speeds: 20, 41 rpm.
9
Measurement speeds: 20, 50, 93 rpm.
10
Measurement speeds: 20, 38 rpm.
11
Measurement speeds: 40, 100, 157, 208 rpm.
12
Measurement speeds: 40, 71 rpm.
13
Measurement speeds: 40, 100, 156 rpm.
14
Measurement speeds: 40, 65 rpm.
15
Measurement speeds: 20, 50, 81 rpm.
16
Measurement speeds: 20, 50 rpm.
17
Measurement speeds: 20, 50, 78 rpm.
18
Measurement speeds: 20, 38 rpm.
