Axial Load Force Ratings (Maximum Radial Load)
Motor 40 rpm 60 rpm 100 rpm 156 rpm 194 rpm
kg (lb) kg (lb) kg (lb) kg (lb) kg (lb)
MPG-A004-031 166 (366) 102 (225) —— 88 (194) 82 (180)
MPG-A004-091
1
166 (366) 123 (272) —— —— ——
MPG-A010-031
2
219 (483) —— 201 (443) 173 (381) ——
MPG-A010-091
3
219 (483) 219 (483) —— —— ——
MPG-A025-031
4
407 (897) —— 254 (559) 213 (471) ——
MPG-A025-091
5
407 (897) 298 (656) —— —— ——
MPG-A050-031
6
625 (1378) 456 (1004) 394 (868) —— ——
MPG-A050-091
7
625 (1378) 483 (1066) —— —— ——
MPG-A110-031
8
1025 (2259) 862 (1899) 715 (1577) —— ——
MPG-A110-091
9
1025 (2259) 936 (2063) —— —— ——
MPG-B010-031
10
219 (483) —— 201 (443) 173 (381) 157 (347)
MPG-B010-091
11
219 (483) 219 (483) —— —— ——
MPG-B025-031
12
407 (897) —— 254 (559) 219 (482) ——
MPG-B025-091
13
407 (897) 293 (645) —— —— ——
MPG-B050-031
14
625 (1378) 456 (1004) 394 (868) —— ——
MPG-B050-091
15
625 (1378) 456 (1004) —— —— ——
MPG-B110-031
16
1025 (2259) 862 (1899) 754 (1662) —— ——
MPG-B110-091
17
1025 (2259) 936 (2063) —— —— ——
1
Measurement speeds: 40, 66 rpm.
2
Measurement speeds: 40, 100, 157 rpm.
3
Measurement speeds: 40, 65 rpm.
4
Measurement speeds: 40, 100, 158 rpm.
5
Measurement speeds: 40, 62 rpm.
6
Measurement speeds: 20, 50, 81 rpm.
7
Measurement speeds: 20, 41 rpm.
8
Measurement speeds: 20, 50, 93 rpm.
9
Measurement speeds: 20, 38 rpm.
10
Measurement speeds: 40, 100, 157, 208 rpm.
11
Measurement speeds: 40, 71 rpm.
12
Measurement speeds: 40, 100, 156 rpm.
13
Measurement speeds: 40, 65 rpm.
14
Measurement speeds: 20, 50, 81 rpm.
15
Measurement speeds: 20, 50 rpm.
16
Measurement speeds: 20, 50, 78 rpm.
17
Measurement speeds: 20, 38 rpm.
