24 MP-Series Integrated Gear Motor Installation Instructions
Publication MP-IN003C-EN-P — April 2003
Radial Load Force Ratings
Motor 40 rpm 60 rpm 100 rpm 156 rpm 194 rpm
kg (lb) kg (lb) kg (lb) kg (lb) kg (lb)
MPG-A004-031 179 (393) —— 162 (356) 139 (307) 130 (286)
MPG-A004-091
1
179 (393) 179 (393) —— —— ——
MPG-A010-031
2
337 (743) —— 286 (631) 246 (543) ——
MPG-A010-091
3
337 (743) 330 (728) —— —— ——
MPG-A025-031
4
478 (1053) —— 406 (895) 342 (753) ——
MPG-A025-091
5
478 (1053) 476 (1050) —— —— ——
MPG-A050-031
6
1724 (3801) 1509 (3325) 1305 (2877) —— ——
MPG-A050-091
7
1724 (3801) 1602 (3530) —— —— ——
MPG-A110-031
8
3144 (6930) 2751 (6062) 2283 (5032) —— ——
MPG-A110-091
9
3144 (6930) 2987 (6583) —— —— ——
MPG-B010-031
10
337 (743) —— 286 (631) 246 (543) 224 (494)
MPG-B010-091
11
337 (743) 321 (707) —— —— ——
MPG-B025-031
12
478 (1053) —— 406 (895) 350 (772) ——
MPG-B025-091
13
478 (1053) 469 (1033) —— —— ——
MPG-B050-031
14
1724 (3801) 1509 (3325) 1305 (2877) —— ——
MPG-B050-091
15
1724 (3801) 1509 (3325) —— —— ——
MPG-B110-031
16
3144 (6930) 2751 (6062) 2407 (5305) —— ——
MPG-B110-091
17
3144 (6930) 2987 (6583) —— —— ——
1
Measurement speeds: 40, 66 rpm.
2
Measurement speeds: 40, 100, 157 rpm.
3
Measurement speeds: 40, 65 rpm.
4
Measurement speeds: 40, 100, 158 rpm.
5
Measurement speeds: 40, 62 rpm.
6
Measurement speeds: 20, 50, 81 rpm.
7
Measurement speeds: 20, 41 rpm.
8
Measurement speeds: 20, 50, 93 rpm.
9
Measurement speeds: 20, 38 rpm.
10
Measurement speeds: 40, 100, 157, 208 rpm.
11
Measurement speeds: 40, 71 rpm.
12
Measurement speeds: 40, 100, 156 rpm.
13
Measurement speeds: 40, 65 rpm.
14
Measurement speeds: 20, 50, 81 rpm.
15
Measurement speeds: 20, 50 rpm.
16
Measurement speeds: 20, 50, 78 rpm.
17
Measurement speeds: 20, 38 rpm.
