Publication 1756-QS001E-EN-P - October 2009 99
Document a Project Chapter 6
RSLogix 5000 software uses different colors for descriptions:
Turn Pass-Through and Append Descriptions On or Off
1. In RSLogix 5000 software, from the Tools menu, choose Options.
2. Select the Display.
3. Turn on (check) or turn off (uncheck) the desired options.
A description in this color Is a
Gray Pass-through description
Black Manually entered description
