59Publication 1756-QS001E-EN-P - October 2009 59
Chapter
4
Program an Equipment Phase
Use PhaseManager software to create an equipment phase and change the default settings for the equipment
phase.
What You Need
You need these items to complete the tasks in this manual:
• Personal computer running RSLogix 5000 software, version 16 or later
• A layout of the system for which you are creating a project
Follow These Steps
5. Create an equipment phase (page 60).
6. Create a state routine (page 60).
7. Manually step through the states (page 61).
8. Configure the initial state for an equipment phase (page 63).
9. Open the configuration for an equipment phase (page 64
).
10. Configure an equipment phase (page 64).
