48 Publication 1756-QS001E-EN-P - October 2009
Chapter 2 Organize a Project
Configure the Controller
If you want to change the configuration of the controller, such as name, chassis size, or slot number, use the
Controller Properties dialog box.
1. Click the Controller Properties button.
2. Change the required properties (some items apply only to certain controllers) and click OK.
