44 Publication 1756-QS001E-EN-P - October 2009
Chapter 2 Organize a Project
Define a Routine for Each Section of Your Machine or Process
To make your project easier to develop, test, and troubleshoot, divide it into routines (subroutines).
1. Identify each physical section of your machine or process.
2. Assign a routine for each of those sections.
Identify the Programming Languages That Are Installed
Follow these steps to determine which programming languages are installed on your version of RSLogix 5000
software.
1. Start RSLogix 5000 software.
2. From the Help menu, choose About RSLogix 5000.
Description of Your Machine or Process
Xxxxx xxxxx xxx
Xxxxx xxxxx xxx
Xxxxx xxxxx xxx
Xxxxx xxxxx xxx
Xxxxx xxxxx xxx
Xxxxx xxxxx xxx
Xxxxx xxxxx xxx
Xxxxx xxxxx xxx
Xxxxx xxxxx xxx
First Section = Routine 1
Second Section = Routine 2
Third Section = Routine 3
