109Publication 1756-QS001E-EN-P - October 2009 109
Chapter
7
Go Online to the Controller
Use this chapter to access the project in the controller so you can monitor, edit, or troubleshoot the
controller.
What You Need
You need these items to complete the tasks in this manual:
• Personal computer running RSLogix 5000 software, version 16 or later, and RSLinx software
• The physical system to which you are connecting
• EtherNet/IP cabling
• EtherNet/IP communication card(s) for the for the module(s) in our sample project
• The project you want to access
Follow These Steps
1. Establish EtherNet/IP communication with the controller (page 110)
2. Go online to a controller (page 116)
