Rockwell Automation Publication D2-3518-3 - May 2013 99

Chapter 9

Selects the source of the PI reference signal.

Provides an internal fixed value for the process setpoint when PI Reference Sel

(126) is set to PI Setpoint.

126 PI Reference Sel

Range: 0 = PI Setpoint

1 = Analog In 1

2 = Analog In 2

3...8 = Reserved

9 = MOP Level

10 = Master Ref

11 = Preset Spd 1

12 = Preset Spd 2

13 = Preset Spd 3

14 = Preset Spd 4

15 = Preset Spd 5

16 = Preset Spd 6

17 = Preset Spd 7

18 = DPI Port 1

19 = DPI Port 2

20 = DPI Port 3

21 = DPI Port 4

22 = DPI Port 5

Default: 0 = PI Setpoint

Access: 1 Path: Speed Command > Process PI
