94 Rockwell Automation Publication D2-3518-3 - May 2013
Chapter 9
Table 7 - Default Values for Preset Speeds 1...7
Specifies which input signal is being used as a trim input.
Specifies if Ref A speed reference or Ref B speed reference is to be trimmed.
Parameter No. Parameter Name Default
101 Preset Speed 1 5.0 Hz
102 Preset Speed 2 10.0 Hz
103 Preset Speed 3 20.0 Hz
104 Preset Speed 4 30.0 Hz
105 Preset Speed 5 40.0 Hz
106 Preset Speed 6 50.0 Hz
107 Preset Speed 7 60.0 Hz
117 Trim In Select
Range: 1 = Analog In 1
2 = Analog In 2
3...8 = Reserved
9 = MOP Level
10 = Reserved
11 = Preset Spd 1
12 = Preset Spd 2
13 = Preset Spd 3
14 = Preset Spd 4
15 = Preset Spd 5
16 = Preset Spd 6
17 = Preset Spd 7
18 = DPI Port 1
19 = DPI Port 2
20 = DPI Port 3
21 = DPI Port 4
22 = DPI Port 5
Default: 2 = Analog In 2
Access: 1 Path: Speed Command > Speed Trim
See also: 90, 93
118 Trim Out Select
Range: See Figure 39
Default: See Figure 39
Access: 1 Path: Speed Command > Speed Trim
See also: 117, 119, 120
