86 Rockwell Automation Publication D2-3518-3 - May 2013

Chapter 9

Value of volts dropped across the resistance of the motor stator. Used only when

Torque Perf Mode (53) is set to Sensrls Vect or SV Economize.

When inverter Autotune (61) is set to Calculate, the value of this parameter is

set according to the motor nameplate parameters, and you cannot write to this

parameter.

Value of RMS motor amps for full motor flux. Used only when Torque Perf

Mode (53) is set to Sensrls Vect or SV Economize.

When inverter Autotune (61) is set to Calculate, the value of this parameter is

set according to the motor nameplate parameters, and you cannot write to this

parameter.

This parameter should be left at its default value of 0.0V AC.

Sets the voltage boost level for starting and acceleration when Custom V/Hz

mode is selected in Torque Perf Mode (53).

62 IR Voltage Drop

Range: 0.0 to Motor NP Volts x 0.25 [0.1V AC]

Default: Based on Drive Rating

Access: 1 Path: Motor Control > Torq Attributes
