80 Rockwell Automation Publication D2-3518-3 - May 2013
Chapter 9
Set to the motor nameplate rated frequency. The motor nameplate base
frequency defines the output frequency when operating at rated voltage, rated
current, rated speed, and rated temperature.
Set to the motor nameplate rated RPM. The motor nameplate RPM defines the
rated speed when operating at motor nameplate base frequency, rated current,
base voltage, and rated temperature. This is used to calculate slip.
Set to the motor nameplate rated power. The motor nameplate power is used
with the other nameplate values to calculate default values for motor parameters
to assist the commissioning process. This is entered in horsepower or in kilowatts
as selected in parameter 46.
Set to the power units shown on the motor nameplate. This parameter
determines the units for parameter 45.
43 Motor NP Hertz
Range: 5.0...250.0 Hz [0.1 Hz]
Default: Based on Drive Type
Access: 0 Path: Motor Control > Motor Data
See also:
44 Motor NP RPM
Range: 60...24000 RPM [1 RPM]
Default: 1780 RPM
Access: 0 Path: Motor Control > Motor Data
See also:
45 Motor NP Power
Range: 0.00...3000.00 [0.01 kW or 0.01 HP]
Default: Based on Drive Type
Access: 0 Path: Motor Control > Motor Data
See also: 46
46 Mtr NP Pwr Units
Range: 0 = Horsepower
1 = kilowatts
Default: Based on Drive Type
Access: 0 Path: Motor Control > Motor Data
See also:
32
