Rockwell Automation Publication D2-3518-3 - May 2013 79

Chapter 9

Displays a fault from the rectifier. The rectifier writes a fault code into this

parameter through a data link.

Set to match the type of motor connected: Induction, Synchronous Reluctance,

or Synchronous Permanent Magnet.

Set to the motor nameplate rated volts. The motor nameplate base voltage

defines the output voltage when operating at rated current, rated speed, and rated

temperature.

Set to the motor nameplate rated full load amps. The motor nameplate FLA

defines the output amps when operating at rated voltage, rated speed, and rated

temperature. It is used in the motor thermal overload and in the calculation of

slip.

35 Rctfr Fault

Range: 0...299

Default: Read Only

Access: 1 Path: Monitor > Application
