Rockwell Automation Publication D2-3518-3 - May 2013 77

Chapter 9

The commanded state of the rectifier.

Frame 3 drives (firmware version 1.x) only:

Figure 32 - Rectifier Control (33) Frame 3

Frame 4 drives (firmware version 2.x) only:

Figure 33 - Rectifier Control (33) Frame 4

33 Rctfr Control

Range: See Figure 32 and Figure 33

Default: N/A

Access: 1 Path: Monitor > Application
