Rockwell Automation Publication D2-3518-3 - May 2013 73

Chapter 9

The analog value of motor ground current. Ground current trip is at about 50%

of drive rated current.

The RMS motor output current value, as follows:

• Parameter 22 displays the phase U RMS current value.

• Parameter 23 displays the phase V RMS current value.

• Parameter 24 displays the phase W RMS current value.

The estimated input power of the drive. This value is calculated as a function of

the output power.

The drive power rating.

21 Ground Current

Range: 0.0...3276.7 [0.1 A]

Default: Read Only

Access: 1 Path: Monitor > Metering
