Rockwell Automation Publication D2-3518-3 - May 2013 71

Chapter 9

The RMS output voltage present at terminals T1, T2, and T3 (U, V, and W).

The output power present at T1, T2, and T3 (U, V, and W).

The output power factor.

The accumulated output energy of the drive.

The accumulated time the drive has been outputting power.

6 Output Voltage

Range: 0.0...600.0V AC [0.1V AC]

Default: Read Only
