Chapter 8
Inverter Parameters Basic Access Level
The inverter parameters available at the Basic level (0) are listed in the table
below.
Rectifier Parameters Basic Access Level
The rectifier parameters available at the Basic level (0) are listed in the table
below.
1 Output Freq 97 TB Man Ref Hi 190 Direction Mode
2 Commanded Freq 98 TB Man Ref Lo 196 Param Access Lvl
3 Output Current 100 Jog Speed 197 Reset To Defalts
12 DC Bus Voltage 101...
107
Preset Speed 1...7 198 Load Frm Usr Set
41 Motor NP Volts 140 Accel Time 1 199 Save To User Set
42 Motor NP FLA 141 Accel Time 2 201 Language
43 Motor NP Hertz 142 Decel Time 1 214 Start Inhibits
44 Motor NP RPM 143 Decel Time 2 216 Dig In Status
45 Motor NP Power 146 S Curve % 217 Dig Out Status
46 Mtr NP Pwr Units 147 Current Lmt Sel 238 Fault Config 1
47 Motor OL Hertz 148 Current Lmt Val 320 Anlg In Config
53 Torque Perf Mode 155 Stop Mode A 322 Analog In 1 Hi
54 Maximum Voltage 156 Stop Mode B 323 Analog In 1 Lo
55 Maximum Freq 157 DC Brake Lvl Sel 325 Analog In 2 Hi
61 Autotune 158 DC Brake Level 326 Analog In 2 Lo
81 Minimum Speed 159 DC Brake Time 342 Analog Out1 Sel
82 Maximum Speed 161 Bus Reg Mode A 343 Analog Out1 Hi
90 Speed Ref A Sel 162 Bus Reg Mode B 344 Analog Out1 Lo
91 Speed Ref A Hi 163 DB Resistor Type 361...
366
Digital In1 Sel...
Digital In6 Sel
92 Speed Ref A Lo 168 Start At PowerUp 380 Digital Out1 Sel
93 Speed Ref B Sel 174 Auto Rstrt Tries 381 Dig Out1 Level
94 Speed Ref B Hi 175 Auto Rstrt Delay 384 Digital Out2 Sel
95 Speed Ref B Lo 184 Power Loss Mode 385 Dig Out2 Level
96 TB Man Ref Sel 185 Power Loss Time –
1 Line Frequency 103 Vdc Reference 164 CAN Bus Off Cnt
2 Input Current R 104 Vdc Command 171...
174
D/A Select (N)
3 Input Current S 105 Current Limit 196 Param Access Lvl
4 Input Current T 106 Input Load Amps 197 Reset to Defalts
5 Active Current 107 Max Motor Volts 198 Load Frm Usr Set
6 Reactive Current 108 Max Motor Freq 199 Save to User Set
