Chapter 6
8. Check that the incoming power is rated correctly.
9. Check the motor installation and length of motor leads.
10. Check that the rating of the transformer (if used) matches the drive
requirements and is connected properly.
11. Verify that a properly sized ground wire is installed and a suitable earth
ground is used. Check for and eliminate any grounds between the motor
frame and the motor power leads. Verify that all ground leads are
unbroken.
12. Visually inspect the liquid-cooling connections for leaks.
Powering Up After
Installation Is Complete
Use the following procedure to verify that the drive is installed correctly and is
receiving the proper line voltage:
1. Turn the input circuit breaker of the drive to the On position.
2. Verify that coolant is flowing through the power module.
3. Follow the start-up procedure in Using the Start-up Routines
on page 53.
