Rockwell Automation Publication D2-3518-3 - May 2013 33
Chapter 2
Optional Equipment
Tab le 3 lists standard LiquiFlo 2.0 kits and options.
Table 3 - Available LiquiFlo 2.0 Kits and Options
Description Model Number Instruction Manual
Operator Interface Module (OIM) RE1LCD LiquiFlo 2.0 AC Drive User Manual,
publication D2-3518. See Using the OIM on
page 235.
OIM LCD Hand-held Cable RECBL-LCD N/A
OIM Door-mount Bezel Kit REBZL-N1 MD60/MD65 Door-Mount NEMA 1 OIM
Bezel Kit (MDI) Instruction Manual,
publication D2-3517
Serial Converter with VS Utilities Software RECOMM-232 VS Utilities Getting Results Manual,
publication D2-3488
