Rockwell Automation Publication D2-3518-3 - May 2013 231

Chapter 10

Contacting Technical Support for Assistance

The Tech Support option in the Diagnostics menu provides information

regarding technical support.

Also, see Rockwell Automation Support

on the back cover of this user manual for

technical support contact information.
