Rockwell Automation Publication D2-3518-3 - May 2013 215
Chapter 10
Diagnostic Parameters
The table below describes the diagnostic parameter values.
Diagnostic Parameter Number Value Displayed
1DPI Error Status
2 Calculated IGBT Junction Temperature
3 Active Current Limit
4 Active PWM Frequency
5 Lifetime MegaWatt Hours
(1)
(1) Use the equation below to calculate total Lifetime MegaWatt Hours.
6 Lifetime Run Time
7 Lifetime Powered Up Time
8 Lifetime Power Cycles
9 Life MegaWatt Hours Fraction
(1)
10 Life MegaWatt Hours Fraction Units
(1)
11...99 Reserved for Factory Use
Value of Code 9
Value of Code 10
------------------------------------------
0.1×
⎝⎠
⎛⎞
Value of Code 5+ Total Lifetime Megawatt Hours=
⎝ ⎠
⎛ ⎞
