Rockwell Automation Publication D2-3518-3 - May 2013 21

Chapter 2

Power Module Components Locations (Frame 4)

Frame 4 Units LF200900CCR and LF201215CCR

The power module section contains the following main components. The

numbered items listed below correspond to the numbers used in Figure 6

and

Figure 7

. Replacement parts are listed in Chapter 10.

1. Combined Power PCB Assembly, 900 A, or

Combined Power PCB Assembly, 1215 A

2. Wire Harness Assembly, Gate Driver

3. Internal Fan, 24V DC

4. Internal Fan, 24V DC

5. Wire Harness Assembly, Internal Fan

6. Wire Harness Assembly, DC Power

7. Wire Harness Assembly, DC Bus Resistors

8. Current Feedback Device, 2000 A

9. Wire Harness Assembly, Current Feedback Device, Rectifier Side

10. Wire Harness Assembly, Current Feedback Device, Inverter Side

11. Wire Harness Assembly, RTD, Recitifier Side

12. Wire Harness Assembly, RTD, Inverter Side

13. Cable Assembly, 40-Pin

14. Combined Control PCB Assembly

15. Combined I/O PCB Assembly

16. RS-485 Communications Assembly (optional)

17. Cable Assembly, 20-Pin (optional)

18. Cable, Mini DIN, 8 Pos., Male/Male, 1 m (3.2 ft)
