194 Rockwell Automation Publication D2-3518-3 - May 2013

Chapter 9

Displays the measured voltage of the –12V power supply.

This parameter is only present on Frame 4 drives. All such drives should have

firmware version numbers in the 2.x series.

Displays the measured voltage that identifies which type of IO board is installed.

This parameter is only present on Frame 4 drives. All such drives should have

firmware version numbers in the 2.x series.

353 Rct PS -12V

Range: -3276.8...3276.7V °C

Default: Read Only

Access: 1 Path: Inputs & Outputs > Temperature etc
