Rockwell Automation Publication D2-3518-3 - May 2013 193
Chapter 9
Displays the measured rectifier coldplate temperature in degrees C. This
parameter is only usable if a coldplate temperature sensor is installed in the drive.
This parameter is only present on Frame 4 drives. All such drives should have
firmware version numbers in the 2.x series.
Displays the measured ambient temperature inside the power module in
degrees C.
This parameter is only present on Frame 4 drives. All such drives should have
firmware version numbers in the 2.x series.
Displays the measured drive power supply temperature in degrees C.
This parameter is only present on Frame 4 drives. All such drives should have
firmware version numbers in the 2.x series.
Displays the measured voltage of the +12V power supply.
This parameter is only present on Frame 4 drives. All such drives should have
firmware version numbers in the 2.x series.
349 Rct Coldplt Tmp
Range: -3276.8...3276.7 °C
Default: Read Only
Access: 1 Path: Inputs & Outputs > Temperature etc
See also:
350 Rct Ambient Tmp
Range: -3276.8...3276.7 °C
Default: Read Only
Access: 1 Path: Inputs & Outputs > Temperature etc
See also:
351 Rct PS Tmp
Range: -3276.8...3276.7 °C
Default: Read Only
Access: 1 Path: Inputs & Outputs > Temperature etc
See also:
352 Rct PS +12V
Range: -3276.8...3276.7V °C
Default: Read Only
Access: 1 Path: Inputs & Outputs > Temperature etc
See also:
