192 Rockwell Automation Publication D2-3518-3 - May 2013

Chapter 9

Displays the measured temperature of the top rectifier IGBT power module in

degrees C.

This parameter is only present on Frame 4 drives. All such drives should have

firmware version numbers in the 2.x series.

Displays the measured temperature of the upper rectifier IGBT power module

in degrees C.

This parameter is only present on Frame 4 drives. All such drives should have

firmware version numbers in the 2.x series.

Displays the measured temperature of the lower rectifier IGBT power module

in degrees C.

This parameter is only present on Frame 4 drives. All such drives should have

firmware version numbers in the 2.x series.

Displays the measured temperature of the bottom rectifier IGBT power module

in degrees C.

This parameter is only present on Frame 4 drives. All such drives should have

firmware version numbers in the 2.x series.

345 Rct IGBT Tmp Top

Range: -3276.8...3276.7 °C

Default: Read Only

Access: 1 Path: Inputs & Outputs > Temperature etc
