Rockwell Automation Publication D2-3518-3 - May 2013 187

Chapter 9

Displays reactive input current at the time of the most recent fault.

Displays DC bus voltage at the time of the most recent fault.

Displays commanded active line voltage at the time of the most recent fault.

Displays commanded reactive line voltage at the time of the most recent fault.

This parameter is for service use only.

225 Fault Amps D

Range: 0.0...3276.7 A [0.1 A]

Default: Read Only
