Rockwell Automation Publication D2-3518-3 - May 2013 181
Chapter 9
Writing a 1 to this parameter resets the rectifier to factory default values.
After a Reset to Defaults operation is performed, the value of this parameter
reverts back to 0 for Ready.
This parameter is not used in the Liquiflo 2.0 rectifier.
This parameter is not used in the Liquiflo 2.0 rectifier.
Writing a 1 to this parameter resets the rectifier elapsed data parameters.
After a Reset Meters operation is completed, the value of this parameter reverts
back to 0 for Ready.
197 Reset to Defalts
Range: 0 = Ready
1 = Factory
2 = Low Voltage
3 = High Voltage
Default: 0
Access: 0 Path: Utility > Drive Memory
See also:
198 Load Frm Usr Set
Range: 0...3
Default: Read Only
Access: 0 Path: Utility > Drive Memory
See also:
199 Save to User Set
Range: 0...3
Default: Read Only
Access: 0 Path: Utility > Drive Memory
See also:
200 Reset Meters
Range: 0 = Ready
1 = MWh
2 = Elapsed Time
Default: 0
Access: 0 Path: Utility > Drive Memory
See also:
