180 Rockwell Automation Publication D2-3518-3 - May 2013
Chapter 9
Increments when a DPI producer/consumer message times out.
Increments when DPI CAN bus is off.
Selects signals to map to a D/A test card.
Contains the present rectifier parameter access level. See Chapter 8
for more
information about parameter access levels.
163 PC Timeout Cnt
Range: 0...255
Default: Read Only
Access: 0 Path: Internal Data > DPI Counters
See also:
164 CAN Bus Off Cnt
Range: 0...65535
Default: Read Only
Access: 0 Path: Internal Data > DPI Counters
See also:
171
172
173
174
D/A Select (N)
Range: 0...65535
Default: Read Only
Access: 0 Path: Internal Data > D/A Output Sel
See also:
196 Param Access Lvl
Range: 0 = Basic
1 = Advanced
Default: 0
Access: 0 Path: Utility > Drive Memory
See also:
