Rockwell Automation Publication D2-3518-3 - May 2013 177
Chapter 9
These parameters are reserved for future use.
Displays the measured ambient temperature inside the power module.
Displays measured average amps normalized to 100.0 for 100% of rectifier rating.
Displays the value of the current limit normalized to 4096 for rated current.
Displays the kWH accumulated over the life of the product.
123
124
125
126
127
128
CPC K1
CPC K2
High Temp Limit
Low Temp Limit
Start Move Time
Delay After Move
Range: 0...65535
Default: 0
Access: 0 Path: Dynamic Control > Cold Plate
See also:
129 Ambient Temp
Range: -20.0...120.0 °C [0.1 °C]
Default: Read Only
Access: 0 Path: Dynamic Control > Cold Plate
See also: 120, 121, 122
150 Input Load Amps
Range: 0.0...100.0
Default: Read Only
Access: 0 Path: Internal Data > Normalized Amps
See also:
151 Current Limit
Range: 0...32767
Default: Read Only
Access: 0 Path: Internal Data > Normalized Amps
See also:
152 Life KWH
Range: 0.0...429496729.5 kWh
Default: Read Only
Access: 0 Path: Internal Data > Total Elapsed
See also:
