176 Rockwell Automation Publication D2-3518-3 - May 2013

Chapter 9

Current Minor Loop integral gain.

The threshold for resetting the voltage loop integrator.

The measured cold plate temperature is displayed as x.x

degrees C.

In drives that do not have a cold plate temperature sensor, this number is not

usable.

The hottest measured inverter IGBT module temperature is displayed as

x.x degrees C. This value is received from the inverter via DPI datalink.

The hottest measured rectifier IGBT module temperature is displayed as

x.x degrees C.

113 CML Kp

Range: 0...65535

Default: Based on drive size

Access: 0 Path: Dynamic Control > Regulator Tuning
