168 Rockwell Automation Publication D2-3518-3 - May 2013

Chapter 9

The rectifier rated RMS input voltage is displayed as x.x V AC.

The rectifier rated RMS input current is displayed as x.x A.

The rectifier software version number is displayed as x.xxx.

The allowed level of imbalance in input voltage entered as x.x%.

An Input V Imbalance fault (fault 226) is generated if Line V Imbalance (23) is

greater than V Imbalance Lmt (60) for this amount of time.

27 Rated Volts

Range 0.0...6553.5 V AC [0.1V AC]

Default: Read Only

Access: 0 Path: Monitor > Drive Data
