Rockwell Automation Publication D2-3518-3 - May 2013 167

Chapter 9

The imbalance in input phase current is displayed as x.x%.

The imbalance in amps is calculated as the larger of:

(largest phase current) – (average phase current), or

(average phase current) – (smallest phase current).

The imbalance in percent is calculated as:

(Imbalance in amps) ÷ (average phase current) x 100.

The imbalance in input phase voltage is displayed as x.x%.

The imbalance in volts is calculated as the larger of:

(largest phase to phase voltage) – (average phase to phase voltage), or

(average phase to phase voltage) – (smallest phase to phase voltage).

The imbalance in percent is calculated as:

(Imbalance in volts) ÷ (average phase to phase voltage) x 100.

The rectifier rated kW is displayed as x.xx kW.

22 Line I Imbalance

Range: 0.0...100.0% [0.1%]

Default: Read Only

Access: 0 Path: Monitor > Metering
