166 Rockwell Automation Publication D2-3518-3 - May 2013
Chapter 9
The hottest measured rectifier IGBT module temperature is displayed as
x.x degrees C.
The calculated rectifier IGBT junction temperature is displayed as x.x degrees C.
The rectifier IT overload calculation is displayed as x.x% where the value of 100.0
is the point where the Rectifier IT Overload fault (fault 219) is generated.
The rectifier I
2
T overload is displayed as x.x% where the value of 100.0 is the
point where the rectifier I2T overload fault (fault 220) is generated.
18 Rctfr Base Temp
Range: -20.0...120.0 °C [0.1 °C]
Default: Read Only
Access: 0 Path: Monitor > Metering
See also:
19 Rctfr IGBT Temp
Range: -20.0...120.0 °C [0.1 °C]
Default: Read Only
Access: 0 Path: Monitor > Metering
See also:
20 Rctfr IT Overld
Range: 0.0...100.0% [0.1%]
Default: Read Only
Access: 0 Path: Monitor > Metering
See also:
21 Rctfr I2T Overld
Range: 0.0...100.0% [0.1%]
Default: Read Only
Access: 0 Path: Monitor > Metering
See also: 106
