164 Rockwell Automation Publication D2-3518-3 - May 2013

Chapter 9

The RMS phase-to-phase input voltage Vst is displayed as x.x V.

The RMS phase-to-phase input voltage Vtr is displayed as x.x V.

The DC bus voltage is displayed as x.x V.

The commanded active input voltage is displayed as x.x V DC.

The commanded reactive input voltage is displayed as x.x V DC.

8 Input Voltage ST

Range: 0.0...3276.7 V AC [0.1V AC]

Default: Read Only
