Rockwell Automation Publication D2-3518-3 - May 2013 163

Chapter 9

The RMS input phase current Is is displayed as x.x A.

The RMS input phase current It is displayed as x.x A.

The active input current is displayed as ±x.x A. Motoring current is positive and

generating current is negative.

The reactive input current is displayed as x.x A. This value should always be

near 0.

The RMS phase-to-phase input voltage Vrs is displayed as x.x V.

3 Input Current S

Range: 0.0...3276.7 A [0.1 A]

Default: Read Only
