Chapter 9
If this input function is open, the integrator for the Process PI loop is allowed to
increase.
28 = PI Reset: If this input function is closed, the integrator for the Process PI
loop is reset to 0.
If this input function is open, the integrator for the Process PI loop integrates
normally.
29 = Pwr Loss Lvl: Do not select the Pwr Loss Lvl input function in
Liquiflo 2.0 drives.
30 = Precharg En: This input function is used to manage disconnection from a
common DC bus. Do not select the Precharg En input function in Liquiflo 2.0
drives.
Type 2 Alarms
Some digital input programming may cause conflicts that result in a Type 2
alarm. For example, Digital In1 Sel set to 5 (Start) in 3-wire control, and Digital
In2 Sel set to 7 (Run) in 2-wire control. See Chapter 10
for more information
about these alarms.
Dig In Status (116) indicates the current state of the digital inputs.
