Rockwell Automation Publication D2-3518-3 - May 2013 151
Chapter 9
Displays the measured voltage of the +12V power supply.
This parameter is only present on Frame 4 drives. All such drives should have
firmware version numbers in the 2.x series.
Displays the measured voltage of the -12V power supply.
This parameter is only present on Frame 4 drives. All such drives should have
firmware version numbers in the 2.x series.
Displays the measured voltage that identifies which type of Comblined I/O
board is installed.
This parameter is only present on Frame 4 drives. All such drives should have
firmware version numbers in the 2.x series.
352 Inv PS +12
Range: -3276.8V...3276.7V °C
Default: Read Only
Access: 1 Path: Inputs & Outputs > Temperature etc
See also:
353 Inv PS -12V
Range: -3276.8V...3276.7V °C
Default: Read Only
Access: 1 Path: Inputs & Outputs > Temperature etc
See also:
354 Inv I/O ID V
Range: -3276.8V...3276.7V °C
Default: Read Only
Access: 1 Path: Inputs & Outputs > Temperature etc
See also:
