150 Rockwell Automation Publication D2-3518-3 - May 2013

Chapter 9

This parameter is only present on Frame 4 drives. All such drives should have

firmware version numbers in the 2.x series.

Displays the measured temperature of the bottom inverter IGBT power module

in degrees C.

This parameter is only present on Frame 4 drives. All such drives should have

firmware version numbers in the 2.x series.

Displays the measured inverter coldplate temperature in degrees C. This

parameter is only usable if a coldplate temperature sensor is installed in the drive.

This parameter is only present on Frame 4 drives. All such drives should have

firmware version numbers in the 2.x series.

Displays the measured ambient temperature of the drive in degrees C.

This parameter is only present on Frame 4 drives. All such drives should have

firmware version numbers in the 2.x series.

Displays the measured drive power supply temperature in degrees C.

This parameter is only present on Frame 4 drives. All such drives should have

firmware version numbers in the 2.x series.

348 Inv IGBT Tmp Bot

Range: -3276.8...3276.7 °C

Default: Read Only

Access: 1 Path: Inputs & Outputs > Temperature etc
