Rockwell Automation Publication D2-3518-3 - May 2013 149

Chapter 9

Sets the user-configurable analog output value when the source value is at

minimum. See Analog Out1 Hi (343) for more information. See AC Line I/O

Board Description (Frame 3 Only) on page 25 through Combined I/O Board

Description (Frame 4 Only) on page 29 for a description of I/O hardware that is

present on this drive and is controlled by the inverter.

Displays the measured temperature of the top inverter IGBT power module in

degrees C.

This parameter is only present on Frame 4 drives. All such drives should have

firmware version numbers in the 2.x series.

Displays the measured temperature of the upper inverter IGBT power module

in degrees C.

This parameter is only present on Frame 4 drives. All such drives should have

firmware version numbers in the 2.x series.

Displays the measured temperature of the lower inverter IGBT power module

in degrees C.

344 Analog Out1 Lo

Range: 4.000...20.000 mA [0.001 mA]

-/+10.000V [0.1V]

0.0...10.000V [0.1V]

Default: 4.0 mA

Access: 0 Path: Inputs & Outputs > Analog Outputs
