Rockwell Automation Publication D2-3518-3 - May 2013 137

Chapter 9

Adapter that currently has exclusive control of the command frequency source

selection.

Adapter that currently has exclusive control of selecting Accel Time 1, 2.

Adapter that currently has exclusive control of selecting Decel Time 1, 2.

Adapter that is presently clearing a fault.

Modules that are currently issuing increases or decreases in MOP command

frequency.

292 Reference Owner

Range: See Stop Owner (288)

Default: Read Only
