118 Rockwell Automation Publication D2-3518-3 - May 2013
Chapter 9
Resets selected meters to zero. After a Reset Meters operation is performed, the
value of this parameter returns to 0 for Ready.
Selects the display language when using an OIM.
Resets selected parameters that change the drive voltage rating, current rating,
scaling, and motor data. Maximum Frequency (55) is affected by changing this
parameter.
Provides a checksum value that indicates whether or not a change in inverter
configuration has occurred (data values only).
200 Reset Meters
Range: 0 = Ready
1 = MWh
2 = Elapsed Time
Default: 0 = Ready
Access: 1 Path: Utility > Drive Memory
See also:
201 Language
Range: 0 = Not Selected
1 = English
2 = Francais
3 = Espanol
4 = Italiano
5 = Deutsch
6 = Reserved
7 = Portugues
10 = Dutch
Default: 0 = Not Selected
Access: 0 Path: Utility > Drive Memory
See also:
202 Voltage Class
Range: 2 = Low Voltage
3 = High Voltage
Default: Based on Drive Type
Access: 1 Path: Utility > Drive Memory
See also: 55
203 Drive Checksum
Range: 0...65535 [1]
Default: Read Only
Access: 1 Path: Utility > Drive Memory
See also:
