112 Rockwell Automation Publication D2-3518-3 - May 2013

Chapter 9

Defines the analog input level that stops the drive. This parameter is not used

with LiquiFlo 2.0 AC drives.

Defines the amount of time at or below Sleep Level before a stop command is

issued. This parameter is not used with LiquiFlo 2.0 AC drives.

Sets the reaction to a loss of input power. If Power Loss Mode is set to:

Coast or Coast Input

• Rectifier can no longer synchronize to the AC line, or

• DC bus voltage is

≤ 73% of its value at the time of the input power loss.

Decel, Decel Input, or Decel Fault

• Rectifier can no longer synchronize to the AC line, or

• DC bus voltage is

≤ 82% of its value at the time of the input power loss.

Continue

• Rectifier can no longer synchronize to the AC line, or

• DC bus voltage is

≤ 305V DC.

182 Sleep Level

Range: 4.000 mA, 0.000V / Wake Level [0.001 mA, 0.001V]

Default: 5.000 mA, 5.000V

Access: 1 Path: Dynamic Control > Restart Modes
