Rockwell Automation Publication D2-3518-3 - May 2013 111
Chapter 9
Enables the Sleep-Wake function. This parameter is not used with LiquiFlo 2.0
AC drives.
Selects the source of the input controlling the Sleep-Wake function. This
parameter is not used with LiquiFlo 2.0 AC drives.
Defines the analog input level that starts the drive. This parameter is not used
with LiquiFlo 2.0 AC drives.
Defines the amount of time at or above Wake Level before a start command is
issued. This parameter is not used with LiquiFlo 2.0 AC drives.
178 Sleep-Wake Mode
Range: 0 = Disabled
Default: 0 = Disabled
Access: 1 Path: Dynamic Control > Restart Modes
See also:
179 Sleep-Wake Ref
Range: 1 = Analog In 1
2 = Analog In 2
Default: 2 = Analog In 2
Access: 1 Path: Dynamic Control > Restart Modes
See also:
180 Wake Level
Range: Sleep Level/20.000 mA, 10.000V [0.001 mA, 0.001V]
Default: 6.000 mA, 6.000V
Access: 1 Path: Dynamic Control > Restart Modes
See also: 181
181 Wake Time
Range: 0.0...30.0 [0.1 sec]
Default: 1.0
Access: 1 Path: Dynamic Control > Restart Modes
See also: 180
