Rockwell Automation Publication D2-3518-3 - May 2013 11

Chapter 1

Manual Conventions

Parameter names: In most instances, parameter names are shown as the

parameter name followed by the parameter number. The parameter name is

preceded by inverter or rectifier for reference.

For example: inverter PI Control (125).

Getting Assistance from

Rockwell Automation

If you have any questions or problems with the products described in this

instruction manual, contact your local Rockwell Automation sales office. For

technical assistance, call 1-888-926-6786, Option 1.

Also, see Rockwell Automation Support

on the back cover of this user manual for

technical support contact information.

Additional Resources

These documents contain additional information concerning related products

from Rockwell Automation.

You can view or download publications at

http:/www.rockwellautomation.com/literature/

. To order paper copies of

technical documentation, contact your local Rockwell Automation sales

representative.

Resource Description

VS Utilities Getting Results Manual, publication D2-3488 Provides information explaining the uses and interface of

VS Utilities, and information to help you complete basic

tasks such as installing the software and starting the

application, and finding instructions to complete more

sophisticated tasks using the online help.

Industrial Automation Wiring and Grounding Guidelines,

publication 1770-4.1

Provides general guidelines for installing a Rockwell

Automation industrial system.

Product Certifications website, http://www.ab.com

Provides declarations of conformity, certificates, and other

certification details.
