Rockwell Automation Publication D2-3518-3 - May 2013 109

Chapter 9

Derivative gain for the bus regulator. Used to control regulator overshoot.

This parameter is not used with LiquiFlo 2.0 AC drives.

Enables/disables the function which reconnects to a spinning motor at actual

RPM when a start command is issued.

Adjusts the responsiveness of the flying start function. Increasing the value in this

parameter increases the responsiveness of the flying start function.

165 Bus Reg Kd

Range: 0...10000

Default: 1000

Access: 1 Path: Dynamic Control > Stop/Brake Modes
