104 Rockwell Automation Publication D2-3518-3 - May 2013

Chapter 9

Sets the rate of deceleration for all speed decreases.

(Max Speed ÷ Decel Time) = Decel Rate

Two decel times exist to enable deceleration rate changes on the fly using a

building automation system command or digital input, if configured.

Sets the percentage of acceleration or deceleration time that is applied to the

ramp as S Curve. Time is added; 1/2 at the beginning and 1/2 at the end of the

ramp.

Selects the source for the adjustment of current limit (i.e., parameter, analog

input, etc.).

Defines the RMS current limit value when Current Lmt Sel (147) = Cur Lim

Va l .

142

143

Decel Time 1

Decel Time 2

Range: 0.1...100.0 sec [0.1 sec]

Default: 10.0 sec

Access: 142 = 0

143 = 0

Path: Dynamic Control > Ramp Rates
