100 Rockwell Automation Publication D2-3518-3 - May 2013

Chapter 9

Selects the source of the PI feedback signal.

Specifies the time required for the integral component to reach 100% of PI Error

Meter (137).

128 PI Feedback Sel

Range: 0 = PI Setpoint

1 = Analog In 1

2 = Analog In 2

3...8 = Reserved

9 = MOP Level

10 = Master Ref

11 = Preset Spd 1

12 = Preset Spd 2

13 = Preset Spd 3

14 = Preset Spd 4

15 = Preset Spd 5

16 = Preset Spd 6

17 = Preset Spd 7

18 = DPI Port 1

19 = DPI Port 2

20 = DPI Port 3

21 = DPI Port 4

22 = DPI Port 5

Default: 2 = Analog In 2

Access: 1 Path: Speed Command > Process PI
