10 Rockwell Automation Publication D2-3518-3 - May 2013
Chapter 1
Firmware Versions
There are two frame types for LiquiFlo 2.0 drives: Frame 3 and Frame 4. See
Chapter 2
for a description of the physical layout, components, and ratings for
each frame type.
Each drive contains two sections: the inverter section and the rectifier section.
Each section contains its own firmware.
• Firmware for Frame 3 drives are version 1.xx series
• Firmware for Frame 4 drives are version 2.xx series
The current drive firmware versions are listed in Ta bl e 1
.
Table 1 - Firmware Versions
See Determining the Product Version on page 227 for instructions on
determining the firmware version currently installed in a drive.
ATTENTION: The drive contains ESD- (Electrostatic Discharge) sensitive parts
and assemblies. Static control precautions are required when installing, testing,
servicing, or repairing the drive. Erratic machine operation and damage to, or
destruction of, equipment can result if this procedure is not followed. Failure to
observe this precaution can result in bodily injury.
ATTENTION: You are responsible for conforming with all applicable local,
national, and international codes. Failure to observe this precaution could result
in damage to, or destruction of, the equipment.
Release Date Firmware Type Current Version
May 2011 Frame 3 inverter application firmware 1.12
May 2011 Frame 3 rectifier application firmware 1.14
June 2011 Frame 4 inverter application firmware 2.12
June 2011 Frame 4 rectifier application firmware 2.12
